2021 Honda CB650R Is Euro 5 And A Beautiful Machine!

0

2021 Honda CB650R Is Euro 5 and as we all know it is in line with the CB1000R, CB300R and CB125R that brought a fresh identity to its naked motorcycle line-up, mixing café racer inspirations with a forward-looking ultra-minimalist look under the ‘Neo Sports Café’ design theme. Aimed at a young demographic that looks to show off in style and enjoy to the maximum a combination of exhilarating four-cylinder engine performance and light, versatile, it has proved a great success. Building on the momentum, for 2021 Honda CB650R receives a major front suspension upgrade, plus a range of detail improvements to enhance comfort, usability and practicality.

The major news of the 2021 Honda CB650R update is the application of 41mm Showa Separate Function Big Piston USD forks* – high-quality suspension that further heighten the bike’s handling ability. EURO5 compliance for the engine has been achieved with no loss of top-end power; other improvements include slightly more forward-set handlebars, improved visibility for the LCD display and USB Type-C charging socket under the seat. New side panels and rear mudguard are minor cosmetic changes.

The 2021 Honda CB650R Is Euro 5 will be available in the following colour options:
Pearl Smoky Gray **NEW**
Mat Gunpowder Black Metallic
Candy Chromosphere Red
Mat Jeans Blue Metallic

New Showa Separate Function Big Piston (SFF-BP) USD forks
Four-piston, radial-mount front brake calipers and floating discs
120/70-ZR17 and 180/55-ZR17 front and rear tyres

2021 HONDA CB650R
The transition since decades of the CB650R

2021 Honda CB650R steel diamond frame uses pressed swingarm pivot plates and twin elliptical spars with a rigidity balance specifically tuned (stiffer around the headstock and more flexible in the spar sections) to deliver balanced handling characteristics, with high levels of rider feedback. Rake is set at 25.5° with trail of 101mm and wheelbase of 1,450mm. Kerb weight is 202.5kg.

Showa’s Separate Function Big Piston (SFF-BP) 41mm USD forks are a major upgrade. A pressure separation damper in one fork tube and spring mechanism in the other deliver high damping performance and lighter weight. Together with the use of a larger sized piston the result is increased feel, bump absorption and control. Adjustable for 7-stage spring preload, the single-tube monoshock operates directly on the curvaceous gravity die-cast aluminium swingarm. Four-piston radial-mount front brake calipers work on 310mm wave-pattern floating discs, and are paired with a single-piston rear caliper and 240mm disc. The ABS is a two-channel system. Cast aluminium wheels mount 120/70-ZR17 and 180/55-ZR17 front and rear tyres.

New side panels and rear mudguard/number plate mount
· Handlebar angle increased for easier low-speed manoeuvring
LCD display now easier to read; USB Type-C socket under the seat

Tightly wrapped and aggressive, the CB650R’s Neo Sports Café style features the signature compact ‘Trapezoid’ proportion of short, stubby tail and short overhang headlight. The long fuel tank is a key motif of the family design; its smooth lines accentuate the solidity of real metal surfaces and crown the engineering of the four cylinder powerplant. It also houses the ignition. New, smaller side panels accentuate the minimalism, as does the rear mudguard, which is now constructed from steel rather than nylon plastic. There’s also now a USB Type-C socket located under the seat, for easy charging of a mobile device. Seat height remains 810mm.

The round headlight is one of the key words of the Neo Sports Café design language. It’s LED, as is the rest of the lighting. Sharp LCD instruments use the CB1000R as a baseline and include a Shift Up, Gear Position and Peak Hold indicator. For 2021 readability has been improved with a change of LED angle and font size. Another detail change is an increase in the handlebar angle, up 3° to 35°. This adjustment makes tight, slow-speed turns and U-turns easier.

2021 HONDA CB650R
2021 HONDA CB650R

2021 Honda CB650R gets the 649cc, DOHC 16-valve engine is tuned to create the purest, most enjoyable mid-sized four cylinder performance possible, with the classically fast ‘pick-up’ through the rev range and hard-hitting, high-revving top end for which Honda’s in-line’s fours are renowned. Peak power of 70kW arrives @ 12,000rpm with peak torque @ 63Nm delivered at 8,500 rpm. An easy 35kW conversion is available for A2 licence holders.

Through the 2021 Honda CB650R update, the only changes to engine specification are for EURO5 compliance; this has required revisions to the ECU, cam lobes, intake timing, exhaust pipe, catalyser and silencer, as well as the addition of a crank pulsar. Direct cam actuation makes for a compact cylinder head; bore and stroke is set at 67mm x 46mm with compression ratio raised of 11.6:1. Iridium spark plugs are employed and twin air ducts – either side of the fuel tank – feed the airbox and produce a throaty intake roar.

Asymmetric piston skirts minimise bore contact and reduce friction. Ferrous spines on the outer surface of the cylinder sleeves reduce oil consumption (and friction) with improved heat transfer and a silent SV cam chain reduces frictional losses by using a Vanadium coating on its pins. Internal water channelling from cylinder head to cylinders does away with most of the exterior hoses.

2021 HONDA CB650R
2021 HONDA CB650R

The engine uses a compact internal architecture, stacked six-speed gearbox and starter layout with the cylinders canted forward 30°. An assist/slipper clutch eases upshifts while managing rear-wheel lock up under hard braking and rapid downshifts. Honda Selectable Torque Control (HSTC) is fitted to manage rear wheel traction; it can be turned off should the rider choose. Fuel consumption of 20.4km/l (WMTC mode) gives a range of over 300km from the 15.4L fuel tank.

Several aluminium parts and aluminium inserts to maximise the Neo Sport Café design that CB650R and CB1000R have in common (meter visor, front mudguard panels, shroud covers, side covers, seat cowl)

Under cowl
Wheel stripes
Tank bag and seat bag – the same as those for Honda’s native flagship the CB1000R
Quick shifter
Front visor
12V socket
Heated grips
Tank pad
